| Wavelength | 10600 nm |
| Laser equipment | Sealed laser device for DC simulation |
| Output Power | 60W |
| Spot size | 0.02~0.05mm² |
| Aiming beam | Red semiconductor laser (650 nm) |
| Beam delivery device | Articulated arm with 6 joints |
| Working Mode | Continuous operation |
| Output Mode | Continuous, single pulse, interval pulse, super pulse |
| Scan range | Max. 20mm x 20mm / Min. 0.1x0.1 |
| Scan Mode | Random, Normal and Mid-scan |
| Energy | 1-60W |
| Distance | 0.1-2.6 mm |
| Cooling system | Circulating water cooling |
| Weight | 31 kg |
| Dimensions | 93*52*36cm |
| Power | 220V/110V |


This system offers various treatment tools to meet patient needs with a wide range of applications and remarkable effects.


8 Scan Patterns: Different graphics are available to meet the needs of various treatment areas.
Superficial Fractional: Enables rapid transmission of continuous pulse trains at the same point.
Fractional System: The 10600nm laser is delivered in a fractional manner, leaving surrounding tissue intact to speed up healing while promoting microcirculation and new cell growth. Perfect for skin firmness, acne scars, stretch marks, and rejuvenation.


Ideal for vaginal tightening, skin resurfacing, and scar removal. Treatment is safe, tested, and painless (patients typically feel only warmth/heat).
